Type FLOW(*) CONDENSER
AIR FLOW
m3/h

Power kW

FITTINGS (**)
BSP
NOISE dB PR DROP Bar DIMENSIONS (mm) WEIGHT Kg DRAIN BSP
l/min m3/h cfm
Cons.
Diss.
H
L
D
EV
EH
SV
SH
VRT 15
183
11
6.5
100
0.25
0.5
1/2"
52
0.01
442
502
363
257
178
319
104
24
1
VRT 20
264
16
9.5
100
0.25
0.5
1/2"
53
0.01
442
502
363
257
178
319
104
24
1
VRT 30
480
29
17
370
0.25
0.6
1/2"
52
0.02
442
502
363
257
178
319
104
24.5
1
VRT 50
732
44
25.8
340
0.25
0.7
1/2"
53
0.03
442
502
363
257
178
319
104
24.5
1
VRT 70
1140
68
40
370
0.28
0.5
3/4"
52
0.02
479
502
410
356
234
439
148
42
1
VRT 100
1620
97
57
340
0.35
1.0
3/4"
51
0.05
479
677
410
356
234
439
148
44
1
VRT 130
2220
133
78.2
410
0.58
1.6
3/4"
53
0.06
479
677
410
356
234
439
148
48
1
VRT 160
2580
155
91.1
800
0.66
1.9
3/4"
58
0.08
479
677
410
356
234
439
148
50
1
VRT 190
3100
185
315
109
0.65
2.2
3/4"
58
0.08
479
677
410
356
234
439
148
63
1
VRT 220
3600
216
127
980
0.8
2.3
11/4"
59
0.09
600
700
490
442
309
547
204
70
1
VRT 270
4500
270
158.8
980
1.1
3.4
11/4"
63
0.14
600
700
490
442
309
547
204
75.4
1
VRT 330
5400
324
190.5
980
1.3
4.3
11/4"
63
0.18
600
700
490
442
309
547
204
77
1
VRT 360
6000
360
212
980
1.3
4.3
11/4"
63
0.18
600
700
490
442
309
547
204
77
1

• VOLTAGE: 230V-1-50Hz - Option:T:1 15V-1-60Hz(**) Connection back face

Type FLOW(*) CONDENSER
AIR FLOW
m3/h

Power kW

FITTINGS (**)
BSP
CONDENSER WATER FLOW
m3/h
DIMENSIONS (mm) WEIGHT Kg DRAIN BSP
m3/min m3/h cfm
Cons.
Diss.
H
L
D
EV
EH
SV
SH
VRT 430
7.2
432
254.1
980
1
3.4
1" 1/2"

844
550
670
770
102
844
100
111
1
VRT 500
8.4
504
296.5
980
1.3
4.3
2"

1100
695
752
1005
100
1100
100
149.2
1
VRT 630
10.5
630
370.6
980
1.3
4.3
2"

1100
695
752
888
322
1020
100
195.2
1
VRT 800
14.4
864
508.2
2250
1.8
6.5
2"

1100
695
752
888
322
1020
100
195.2
1

• VOLTAGE: 230V-1-50Hz or 400 V-3-50Hz (**) Connection back face.

VRT 950
15.6
936
550.6
2250
1.8
6.5
3"

1325
700
800
1020
323
1230
100
248.4
2*
VRT 1100
18.3
1098
645.9
2250
2.3
8.5
3"

1325
700
800
1020
323
1230
100
248.4
2
VRT 1300
21
1260
741.1
2250
2.3
8.5
3"

1325
700
800
1020
323
1230
100
251.4
2
VRT 1500
24
1440
847
5000
3
8.5
3"

1420
1120
1000
1115
325
1330
100
382.7
2
VRT 1700
28.5
1710
1005.9
4800
3.7
13.6
3"
0.7
1360
1120
1000
1060
325
1270
100
385.2
2
VRT 2100
34.8
2088
1228.2
7000
4.7
13.6
3"
1.0
1360
1120
1000
1060
325
1270
100
425.2
2
VRT 2300
38.4
2304
1355.2
7000
5.2
15.4
3"
1.0
1360
1400
1000
1060
325
1270
100
430.2
2
VRT 2700
44.4
2664
1567
6600
6.10
18.0
4"
1.2
1460
1400
1120
695
970
1196
970
470
2
VRT 3200
52.2
3132
1842.3
6000
6.74
20.6
4"
1.6
1460
1400
1120
695
970
1196
970
470
2
VRT 4100
67.8
4068
2392.9
7600
9.2
27.5
4"
2
1460
1480
1500
695
970
1196
970
770
2
VRT 4700
78
4680
2752.9
16600
9.75
30.3
DN 150
4.5
1460
1480
1500
695
970
1196
970
820
2
VRT 5600
93
5580
3282.3
16100
12
36.7
DN 150
3.15
1800
1800
1500
695
970
1196
970
940
2
VRT 6300
105
6300
3705.9
16100
14
43.5
DN 150
4.15
1800
1800
1500
695
970
1196
970
1000
2
VRT 7200
120
7200
4235.3
16100
16
49.5
DN 150
3.85
1800
1800
1500
695
970
1196
970
1050
2



• VOLTAGE: 400V-3-50Hz (**) Connection back face.   • FOR EXAMPLE, FOR CHOOSING THE CORRECT DRYER:
• FOR CORRECT SIZING PLEASE USE THE CORECTION FACTORS:
INLET T0 0C
30
35
40
45
50
60
70
F1
0.85
1
1.18
1.39
1.67
2.1
*
AMBIENT T0
22
25
30
35
40
45
50
60
F2
0.92
1
1.07
1.14
1.22
1.35
1.50
*
PRESSURE BAR
0
1
2
4
6
7
8
10
12
14
16
20
50
F3
X
X
X
1.25
1.06
1
0.96
0.9
0.86
0.82
0.8
*
*


If a compressor delivers 100m3/h at 4 bars and the dryer inlet temperature is 450C ambient temperature is 350C Please choose your dryer as follows;
100 x 1.25 x 1.14 x 1.39 = 198 m3/h
The correct dryer for this application is VT220
Correct flow = Requested flow x F1 x F2 x F3
(*): Please contact us.

Refrigerant: R134a from VRT15 to VRT1700, R404a from VRT2100
(*) Flow given at'atmospheric pressure' at 200C (ISO 1217) in accordance with normes ISO 7183-8573-1 and Pneurop 6611 - Class 4-7 bar - 35 C IN 25 0C ambient.

Maximum Pressure: Maximum Temperature: Automatic Drain:
• With manual drain 40 bar • Inlet : 700C • Timed drain
• With automatic drain 16 bar • Ambient : 600C • Pneumatic operated membrane valve (2)
• OPTIONS: Just put following suffix requested after the reference number of the dryer.
HP : Maximum Pressure 40 bar. REP : Alarm Report DC : Condensate drain.
VHP : Maximum Pressure 200 bar. E : Water condenser SI : Ambient temperature until -200C
V : Vacuum Operated. T : Three pheases power supply. HDD: Ambient temperature until +600C
